Product Parameters
|
Product Code |
ACL1016R10-BF |
|
Product Brand |
CHAO WEI |
|
Certification Type |
SGS |
|
Product Name |
Aluminum based copper clad laminate |
|
Product Size (mm) |
1000*1200 |
|
Insulation layer material |
Resin |
|
Total thickness (mm) |
1.6mm |
|
physical total thickness (mm) |
1.52mm |
|
Copper foil thickness (um) Optional |
15/18/25/35 um |
|
Thermal conductivity coefficient W/(m·K) |
1W/(m·K) |
|
With or Y/N Blue Film |
Y |
Product Test Report
|
Test Item |
Testing Basis |
Test Value |
|
Peel Strength |
GJB 1651-1993 / SJ 20780-2000 |
AVG 1.04 N/mm |
|
Surface Resistivity |
GJB 1651-1993 / SJ 20780-2000 |
Min:3.2E+08（MΩ） |
|
Volume Resistivity |
GJB 1651-1993 / SJ 20780-2000 |
Min:5.5E+06（MΩꞏm） |
|
Breakdown Voltage |
GJB 1651-1993 / SJ 20780-2000 |
Min:4.9 kV |
|
Thermal Shock |
GB/T 4722-1992 / SJ 20780-2000 |
No layering or bubbling phenomenon occurred |
|
Thermal Conductivity Coefficient |
ASTM D 5470-17 |
0.81 W/（m.K） |
|
Thermal Resistance（Kꞏc㎡/W） |
ASTM D 5470-17 |
1.34 K.c㎡/W |
|
Dielectric Constant & Dielectric Loss Factor (1 MHz) |
GJB 1651-1993 / SJ 20780-2000 |
3.9C²/(N·M²) |
|
Glass Transition Temperature & Curing Factor |
IPC-TM-650 |
2.23Tg（℃） |
Application Area
Main applications:
1. LED lighting
2. Communication equipment
3. Aerospace field
4. Automotive electronic modules
Factory advantages
1. Production experience: Chaowei Co., Ltd. has over 10 years of production experience since its establishment.
2. Quality System: The product has a complete quality process management system from raw materials to aluminum based copper clad plates, including pressure resistance testing, oxidation resistance testing, heating testing, density and impurity testing, energy testing, and other systems.
3. Collaboration experience: Collaborated with many large and small and medium-sized enterprises, including TCL, FCL, BULL, HUAYI, Midea, MUSENLIN, NVC and other companies and brands.
